| Description | Unit | Parameter value | |
| Engine model | Cummins 6BT5.9-C130-2 | ||
| Rated power/speed | kw(r/min) | 97(2200) | |
| Overall dimension (standard) | 8015X2380X3050 | ||
| Total weight (standard) | kg | 11000 | |
| Tire specification | 13.00-24 | ||
| Ground clearance (front axle) | mm | 515 | |
| Tread | mm | 2020 | |
| Space of front and rear axles | mm | 5780 | |
| Forward velocity | km/h | 5/8/13/20/30/42 | |
| Reverse speed | km/h | 5/13/30 | |
| Tractive effort f=0.75 | kN | 61.3 | |
| Maximum gradeability | % | 20 | |
| Tire inflation pressure | kPa | 300 | |
| Working system pressure | MPa | 16 | |
| Transmission pressure | MPa | 1.3-1.8 | |
| Maximum steering angle of front wheel | ±49° | ||
| Maximum slant angle of front wheel | ±17° | ||
| Maximum oscillating angle of front axle | ±15° | ||
| Maximum oscillating angle of equilibrium box | ±16° | ||
| Maximum steering angle of frame | ±27° | ||
| Minimum turning radius | m | 6.6 | |
| Scrape knife | Maximum lift height | mm | 410 |
| Maximum cutting depth | mm | 515 | |
| Maximum tilt angle | 90° | ||
| Cutting angle | 54°-90° | ||
| Angle of revolution | 360° | ||
| Length & chord height | mm | 3048×610 |
